Square Rimless Wall Hung Pan For Australian & European Distributors | WaterMark, WELS 4-Star, CE (Model I-05BS WHP)

Item	Specification
Model	I-05BS WHP
Product type	Wall hung WC pan, pan only
Bowl shape	Square
Rim design	Rimless
Material	Vitreous china
Finish	Gloss white glaze
Flushing method	Washdown
Trap type	P-trap, horizontal outlet
Overall size (L x W x H)	495 x 365 x 365 mm
Base width	280 mm
Fixing bolt centres	180 mm, Ø15 holes
Outlet	Ø100 mm (spigot 99 mm measured)
Flush inlet	Ø55 mm
Water seal depth	69 mm
Flush volume	4.5 / 3 L dual flush (with G3004 concealed cistern)
Average flush volume	3.2 L
WELS rating	4 Star (AS/NZS 6400:2016)
WaterMark licence	WMKA20080
Australian standards tested	AS 1172.1:2014, AS 1172.2:2014
European compliance	CE marked, Declaration of Performance on request
Static load test	400 kg, no cracking, splitting or crazing
Water absorption	0.22% average (0.21–0.23%)
Test report	No. 2020ZJP02119, CNAS-accredited national laboratory
Seat	Soft-close slow-down quiet seat, matched to the pan
Cistern	Not included (G3004 concealed cistern sold separately)
Installation	In-wall concealed cistern frame with 180 mm fixings
MOQ	50 pcs per model
Lead time	90 days after deposit
OEM / private label	Logo under glaze, custom carton and installation sheet
Samples	Available; buyer pays sample fee and freight

Most returns on imported wall-hung pans come down to fixings, not ceramics. That's why the connection points here match what most in-wall frames are built around:

Fixing bolt centres: 180mm, Ø15 holes

Outlet: Ø100 (spigot measured at 99 mm in testing, accepts a standard pan connector)

Flush inlet: Ø55

Projection 495 mm, width 365 mm, body height 365 mm

A plumber in Melbourne or Munich can hang it on a frame that's already in the wall, with no adapters and no extra drilling. If you sell your own fixing kits, we can leave the bolts out of the box. If you'd rather stock one complete SKU, we'll pack them in.

Plenty of factories call a pan "fully tested". Here are the numbers your compliance team will actually look for:

Solids discharge: 4 of 4 test pieces cleared in all 10 runs

Paper discharge: passed at full and reduced flush, 3 runs each

Splash test: no water over the rim in 6 of 6 flushes

Rimless wetting test: bowl washed clean below 85 mm from the top face

Liquid contaminant after reduced flush: 3.2%

Static load: 400 kg, no cracking, splitting or crazing

Water absorption: 0.21–0.23% across three samples

Chemical resistance and crazing: no change after testing

The full 8-page report goes out with every quote. Don't settle for a summary sheet from any supplier.

Australia: Tested to AS 1172.1 and AS 1172.2, with water efficiency rated under AS/NZS 6400. The average flush came out at 3.2 L, which earns the 4-Star WELS rating. One detail many importers miss: the rating applies to the pan together with its matched cistern, our G3004 concealed cistern. If you plan to pair this pan with another cistern brand, talk to us before you list the WELS number on your site.

Europe: The pan ships CE marked, and the Declaration of Performance and technical file are available for your importer records. It clears at 4.5/3 L, so it also handles frames set to 6/3 L, which is still common in EU renovation work.

We print cartons per market, so Australian and EU stock never get mixed up in your warehouse.

Architects in both regions are specifying square bowls for apartment rebuilds and mid-range hotels right now, and round pans in the same price band are getting harder to move. Without a rim, there's no hidden channel for scale and bacteria to build up in. That means fewer "it won't come clean" complaints coming back to your counter. The glaze is fully fused to the body and passed the surface check under 300 lx lighting at 550 mm.

When a contractor asks you for a square rimless wall hung pan in gloss white that fits their existing frames, this is the model you can quote on the spot.

MOQ: 50 pcs per model, mixed container loads accepted

Lead time: 90 days after deposit

Annual output: about 3.5 million pieces across three tunnel kilns (one 126 m, two 82 m), so your repeat orders are fired on the same curve as your first batch

OEM: your logo under the glaze, your own carton and installation sheet

Exporting since 1955 to buyers across the US, Europe, Australia and the Middle East

Is the cistern included? No. This is a pan-only wall hung WC pan, and the G3004 concealed cistern is sold separately.

Does it come with a seat? Yes. It comes with a matching soft-close seat that lowers slowly and quietly, with no slamming. The seat can be packed in the same box or shipped separately.

Can I get a sample before a container order? Yes. Samples are available for quality checking. The buyer covers the sample fee and the freight.

Send us your target frame brand and annual volume. We'll come back with a price, the full test report and a fixing drawing your installers can check before you order.
